2023 Rocky Mountain Instinct X0 Transmission Custom
X0 Transmission + Black Label Wheels
$8,999.00 $6,499.00
Free shipping or in-store pickupSpecs
- Wheel Size: Variable
- Front Travel: 150mm
- Rear Travel: 140mm
- Frame Material: Carbon
Geometry Data By Frame Size
Measurements primarily in millimeters (mm) unless otherwise noted.
29" in S / M / L / XL
| RIDE-9 setting | POS.1 Slack | POS.2 | POS.3 | POS.4 | POS.5 Neutral | POS.6 | POS.7 | POS.8 | POS.9 Steep |
|---|---|---|---|---|---|---|---|---|---|
| Top Tube Horizontal (mm) | 583 / 698 / 638 / 671 | 583 / 698 / 637 / 671 | 582 / 608 / 637 / 670 | 582 / 608 / 637 / 670 | 582 / 608 / 636 / 670 | 581 / 607 / 636 / 669 | 581 / 608 / 636 / 669 | 581 / 607 / 635 / 669 | 580 / 607 / 635 / 668 |
| Head Tube Angle (deg) | 65 / 65.1 / 65.1 / 65.1 | 65.2 / 65.3 / 65.3 / 65.3 | 65.4 / 65.5 / 65.5 / 65.5 | 65.4 / 65.5 / 65.5 / 65.5 | 65.7 / 65.7 / 65.7 / 65.7 | 65.8 / 65.8 / 65.8 / 65.8 | 65.8 / 65.8 / 65.8 / 65.8 | 66.1 / 66 / 66 / 66 | 66.3 / 66.2 / 66.2 / 66.2 |
| Head Tube Length (mm) | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 | 90 / 95 / 110 / 125 |
| Seat Tube Angle (deg) | 76 / 76.1 / 76.1 / 76.1 | 76.2 / 76.3 / 76.3 / 76.3 | 76.4 / 76.5 / 76.5 / 76.5 | 76.4 / 76.5 / 76.5 / 76.5 | 76.7 / 76.7 / 76.7 / 76.7 | 76.8 / 76.8 / 76.8 / 76.8 | 76.8 / 76.8 / 76.8 / 76.8 | 77.1 / 77 / 77 / 77 | 77.3 / 77.2 / 77.2 / 77.2 |
| Seat Tube Length (mm) | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 | 380 / 420 / 445 / 480 |
| Rear Centre (mm) | 438-449 / 438-449 / 438-449 / 438-449 | 438-449 / 437-448 / 437-448 / 437-448 | 437-448 / 437-448 / 437-448 / 437-448 | 437-448 / 437-448 / 437-448 / 437-448 | 437-448 / 437-448 / 437-448 / 437-448 | 437-448 / 437-448 / 437-448 / 437-448 | 437-448 / 437-448 / 437-448 / 437-448 | 436-447 / 436-447 / 436-447 / 436-447 | 436-447 / 436-447 / 436-447 / 436-447 |
| Bottom Bracket Drop (mm) | 45 / 43 / 43 / 43 | 42 / 41 / 41 / 41 | 39 / 39 / 39 / 39 | 39 / 39 / 39 / 39 | 37 / 36 / 36 / 36 | 34 / 33 / 33 / 33 | 34 / 34 / 34 / 34 | 31 / 31 / 31 / 31 | 28 / 28 / 28 / 28 |
| Reach (mm) | 430 / 456 / 481 / 511 | 433 / 458 / 483 / 513 | 435 / 460 / 485 / 515 | 435 / 460 / 485 / 515 | 437 / 462 / 487 / 517 | 439 / 464 / 489 / 519 | 439 / 464 / 489 / 519 | 441 / 466 / 491 / 521 | 444 / 468 / 493 / 523 |
| Stack (mm) | 615 / 619 / 633 / 646 | 614 / 618 / 631 / 645 | 612 / 616 / 629 / 643 | 612 / 616 / 630 / 643 | 611 / 615 / 628 / 642 | 609 / 613 / 627 / 640 | 609 / 614 / 627 / 640 | 608 / 612 / 625 / 639 | 606 / 610 / 624 / 637 |
| Standover Height (mm) | 742 / 798 / 798 / 798 | 744 / 799 / 799 / 799 | 745 / 800 / 800 / 800 | 746 / 800 / 800 / 800 | 749 / 801 / 801 / 801 | 750 / 802 / 802 / 802 | 751 / 802 / 802 / 802 | 754 / 803 / 803 / 803 | 756 / 804 / 804 / 804 |
| Wheelbase (mm) | 1182 / 1210 / 1241 / 1277 | 1182 / 1209 / 1241 / 1277 | 1182 / 1209 / 1241 / 1277 | 1182 / 1209 / 1241 / 1277 | 1182 / 1209 / 1240 / 1277 | 1182 / 1209 / 1240 / 1277 | 1182 / 1209 / 1240 / 1277 | 1182 / 1209 / 1240 / 1276 | 1181 / 1208 / 1240 / 1276 |
Detailed Specs By Build Kit
| Build Kit | Alloy 10 | Alloy 30 | Alloy 50 | Carbon 30 | Carbon 50 | Carbon 70 | Carbon 90 |
|---|---|---|---|---|---|---|---|
| Frame | FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle | FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle | FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle |
| Fork | RockShox Recon Silver RL 150mm | 42mm Offset | RockShox 35 Gold RL 150mm | 27.5 = 37mm Offset | 29 = 42mm Offset | Fox 36 Float EVOL GRIP Performance Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset | Marzocchi Z2 Float EVOL Rail 150mm | 44mm Offset | Fox 36 Float EVOL GRIP Performance Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset | Fox 36 Float EVOL FIT4 Performance Elite Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset | Fox 36 Float EVOL FIT4 Factory Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
| Front Travel | 150mm | 150mm | 150mm | 150mm | 150mm | 150mm | 150mm |
| Rear Travel | 140mm | 140mm | 140mm | 140mm | 140mm | 140mm | 140mm |
| Shock | RockShox Deluxe Select | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ | RockShox Deluxe Select+ | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ | Fox Float X Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ | Fox Float DPS Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ | Fox Float DPS Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ | Fox Float X Performance Elite | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ | Fox Float X Factory | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ |
| Headset | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race | FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race | FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race | FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m | Rocky Mountain 35 CNC | 0° Rise | All Sizes = 40m |
| Handlebar | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp | Race Face Next R | 780mm Width | 20mm Rise | 8° Backsweep | 4° Upsweep | 35mm Clamp |
| Grips | Rocky Mountain Lock On Light | ODI Elite Pro Lock On | ODI Elite Pro Lock On | Rocky Mountain Lock On Light | ODI Elite Pro Lock On | ODI Elite Pro Lock On | ODI Elite Pro Lock On |
| Brakes | Tektro HD-M275 | Shimano Pad Compatible | F:Tektro 180mm | R:Tektro 180mm | Shimano MT4120 4 Piston | Resin Pads | F:Shimano RT30 180mm | R:Shimano RT30 180mm | Shimano MT6120 4 Piston | Metal Pads | F:Shimano RT64 180mm | R:Shimano RT64 180mm | Shimano MT4120 4 Piston | Resin Pads | F:Shimano RT30 180mm | R:Shimano RT30 180mm | Shimano SLX Trail 4 Piston | Metal Pads | F:Shimano RT66 180mm | R:Shimano RT66 180mm | Shimano XT Trail 4 Piston | Metal Pads | F:Shimano RT66 180mm | R:Shimano RT66 180mm | Shimano XTR Trail 4 Piston | IceTec Metal Pads | F:Shimano RT86 180mm | R:Shimano RT86 180mm |
| Shifters | Shimano Deore 11spd | Shimano Deore 12spd | Shimano SLX | Shimano Deore 12spd | Shimano XT | Shimano XT | Shimano XTR |
| Rear Derailleur | Shimano Deore 11spd | Shimano Deore 12spd | Shimano XT | Shimano Deore 12spd | Shimano XT | Shimano XT | Shimano XTR |
| Cranks & Chanring | Rocky Mountain Microdrive | 32T |Sram 76mm BCD | 24mm Spindle | Crank Length: XS = 165mm | SM - XL = 170mm | Shimano Deore | 32T | 24mm Spindle | 170mm Crank Length | Race Face Ride C" | 32T | 24mm Spindle | Crankarm Length: XS = 165mm | SM - XL = 170mm | Shimano Deore | 32T | 24mm Spindle | 170mm Crank Length | Race Face Aeffect C" | 32T Steel | 24mm Spindle | Crankarm Length: XS = 165mm Crankarm | SM - XL = 170mm | Shimano XT | 32T | 24mm Spindle | Crankarm Length: XS = 165mm Crankarm | SM - XL = 170mm | Race Face Era C" | 32T | 30mm Spindle | Crank Length = 170mm |
| Bottom Bracket | Rocky Mountain Sealed BB92 - Shimano Compatible | Shimano SM-BBMT500 | Shimano SM-BBMT500 | Shimano SM-BBMT500 | Shimano SM-BBMT500 | Shimano SM-BBMT500 | Race Face BB92 30mm |
| Cassette | SunRace CSMS8 EA1 11-51T | Shimano Deore 10-51T 12spd | Shimano Deore 10-51T 12spd | Shimano Deore 10-51T 12spd | Shimano SLX 10-51T | Shimano XT 10-51T | Shimano XTR 12s 10-51T |
| Chain | KMC X11-1 | Shimano M6100 | Shimano M6100 | Shimano M6100 | Shimano M6100 | Shimano M8100 | Shimano XTR 12s |
| Front Hub | Rocky Mountain Sealed Boost 15mm | Rocky Mountain Sealed Boost 15mm | Rocky Mountain Sealed Boost 15mm | Rocky Mountain Sealed Boost 15mm | Rocky Mountain Sealed Boost 15mm | Rocky Mountain Sealed Boost 15mm | Rocky Mountain Sealed Boost 15mm |
| Rear Hub | Novatec D462 Sealed Boost 148mm | Novatec D462 Sealed Boost 148mm | Shimano SLX Boost 148mm | Novatec D462 Sealed Boost 148mm | DT Swiss 370 Boost 148mm | 18T Star-Ratchet | DT Swiss 370 Boost 148mm | 18T Star-Ratchet | DT Swiss 350 Boost 148mm | 36T Star-Ratchet |
| Spokes | 2.0 Stainless | 2.0 Stainless | DT Swiss Competition 2.0/1.8/2.0 | 2.0 Stainless | DT Swiss Champion 2.0 | DT Swiss Competition 2.0/1.8/2.0 | DT Swiss Competition 2.0/1.8/2.0 |
| Rims | Rocky Mountain TR30 Tubeless | 32H | Tubeless Compatible - Tape / Valves / Sealant Not Incl | WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl | WTB ST Light i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl | WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl | WTB ST Light i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl | Race Face AR 30 | 32H | Tubeless Ready - Tape / Valves Incl | Race Face ARC Carbon 31 | 32H | Tubeless Ready - Tape / Valves Incl |
| Tires | F: WTB Trail Boss Comp 29 x 2.4 // R: WTB Trail Boss Comp 29 x 2.4 | F: Maxxis Minion DHF 2.5 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready | F: Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready | F: Maxxis Minion DHF 2.5 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready | F: Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready | F: Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready | F: Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready |
| Seatpost | Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm | Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm | Rocky Mountain Toonie Drop Alloy 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm | Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm | Rocky Mountain Toonie Drop Alloy 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm | Race Face Turbine R (by Fox) Dropper 30.9mm | XS - SM = 125mm | MD = 150mm | LG = 175mm | XL = 200mm | Fox Transfer Factory Series 30.9mm | XS - SM = 125mm | MD = 150mm | LG = 175mm | XL = 200mm |
| Saddle | WTB Volt 142 | WTB Volt 142 | WTB Volt Race 142 | WTB Volt Race 142 | WTB Volt Race 142 | WTB Volt Race 142 | WTB Volt Race 142 |
| Price | $2899 | $3399 | $4599 | $4699 | $5799 | $6999 | $9799 |
Disclaimers
- Mountain bikes, road bikes, and gravel bikes are fully assembled prior to shipping. Del Sol, E11even, Haro, and Tuesday bikes will ship as received from the original manufacturer in the original manufacturer packaging. All other bikes including kids bikes, cruisers, bmx bikes, etc. may be shipped in the original manufacturers packaging.
- While every effort is made to ensure the accuracy of the above information, it is entered by real live humans and humans make mistakes. The majority of the bikes on our website are specced exactly as they come from the manufacturers. Any upgrades or customizations will be listed separately. Please confirm with Airpark Bike Co if there are any questions about the included specification for the bike you are looking at.
- Bike component specifications including (but not limited to) suspension, drivetrain, brakes, tires, and wheels are subject to change by the manufacturer without notice.
- Any indicated component upgrades included or purchased in conjunction with a bike will be replacements for OEM components on the bike. The bike will ship with the upgraded components installed, but will not include the OEM components. Credit for the OEM components are factored into the pricing for upgrades.
