2023 Norco Sight X0 Transmission Custom
X0 Transmission + Black Label Wheels
$8,999.00 $6,499.00
Free shipping or in-store pickupOut of Stock
Specs
- Wheel Size: 29"
- Front Travel: 160mm
- Rear Travel: 150mm
- Frame Material: Carbon
Key Features
About This Bike
Geometry Data By Frame Size
Measurements primarily in millimeters (mm) unless otherwise noted.
27.5" Wheels
| Size | S | M | L | XL |
|---|---|---|---|---|
| Front Travel | 160 | 160 | 160 | 160 |
| Rear Travel | 150 | 150 | 150 | 150 |
| Reach | 425 | 455 | 485 | 515 |
| Stack | 585 | 594 | 603 | 612 |
| Head Tube Angle | 63.5 | 63.5 | 63.5 | 63.5 |
| Fork Offset | 37 | 37 | 37 | 37 |
| Seat Tube Length | 370 | 395 | 435 | 465 |
| Effective Seat Tube Angle | 77 | 77.3 | 77.7 | 78 |
| Rear Centre Length | 430 | 435 | 440 | 445 |
| Bottom Bracket Drop | 15 | 15 | 15 | 15 |
| Bottom Bracket Height | 342 | 342 | 342 | 342 |
| Horizontal Top Tube | 560 | 588 | 617 | 645 |
| Wheelbase | 1180 | 1220 | 1259 | 1299 |
| Standover | 668 | 677 | 683 | 701 |
| Head Tube Length | 100 | 110 | 120 | 130 |
| Trail | 136 | 137 | 137 | 137 |
| Recommended Seatpost Drop | 150 | 170 | 170 | 200 |
| Maximum Post Insertion | 225 | 250 | 270 | 270 |
| Stem Length | 40 | 40 | 40 | 40 |
| Crank Length | 170 | 170 | 170 | 170 |
| Tire Size | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" |
| Water Bottle Compatible | 1x620mL | 1x750mL | 1x750mL | 1x750mL |
29" Wheels
| Size | S | M | L | XL |
|---|---|---|---|---|
| Front Travel | 160 | 160 | 160 | 160 |
| Rear Travel | 150 | 150 | 150 | 150 |
| Reach | 425 | 455 | 485 | 515 |
| Stack | 603 | 612 | 621 | 630 |
| Head Tube Angle | 64 | 64 | 64 | 64 |
| Fork Offset | 42 | 42 | 42 | 42 |
| Seat Tube Length | 370 | 395 | 435 | 465 |
| Effective Seat Tube Angle | 77 | 77.3 | 77.7 | 78 |
| Rear Centre Length | 430 | 435 | 440 | 445 |
| Bottom Bracket Drop | 25 | 25 | 25 | 25 |
| Bottom Bracket Height | 350 | 350 | 350 | 350 |
| Horizontal Top Tube | 564 | 593 | 621 | 649 |
| Wheelbase | 1183 | 1222 | 1262 | 1301 |
| Standover | 682 | 687 | 704 | 726 |
| Head Tube Length | 90 | 100 | 110 | 120 |
| Trail | 136 | 136 | 136 | 136 |
| Recommended Seatpost Drop | 150 | 170 | 170 | 200 |
| Maximum Post Insertion | 225 | 250 | 270 | 270 |
| Stem Length | 40 | 40 | 40 | 40 |
| Crank Length | 170 | 170 | 170 | 170 |
| Tire Size | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" | 2.35"-2.6" |
| Water Bottle Compatible | 1x620mL | 1x750mL | 1x750mL | 1x750mL |
Detailed Specs By Build Kit
| KIT | A Frame Kit | C Frame Kit | A3 | A2 | A1 | C3 | C2 SRAM | C2 Shimano | C1 | C SE |
|---|---|---|---|---|---|---|---|---|---|---|
| FRAME | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Sight carbon main frame and seatstay , 150mm travel | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Aluminum All-Mountain, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ | Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" Options, Ride Aligned™ |
| FORK | - | - | RockShox Yari RC, Motion Control, 160mm, 37mm Offset (27.5), 44mm Offset (29) | Fox FLOAT 36 Rhythm, 160mm, Sweep Adjust, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Ultimate, Charger 2 RC2, 160mm, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Select, Charger RC, 160mm, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Ultimate, Charger 2 RC2, 160mm, 37mm Offset (27.5), 44mm Offset (29) | Fox Performance Elite 36, GRIP 2, 160mm, HSC, LSC, HSR, LSR, 37mm Offset (27.5), 44mm Offset (29) | RockShox Lyrik Ultimate, Charger 2 RC2, 160mm, 37mm Offset (27.5), 44mm Offset (29) | Fox Factory FLOAT 36, GRIP 2, 160mm, HSC/LSC/LSR |
| REAR SHOCK | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | Fox Factory FLOAT X2, HSC/LSC, HSR/LSR, 185x52.5 Trunnion | RockShox Super Deluxe Select R, LINM Tune, 185x52.5mm Trunnion | Fox Performance Float X2, LSC, LSR, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | Fox Performance FLOAT X2, HSC/LSC, HSR/LSR, 185x52.5mm Trunnion | RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion | Fox Factory FLOAT X2, HSC/LSC, HSR/LSR, 185x52.5mm Trunnion |
| REAR SHIFTER | - | Shimano Deore SL-M6100-R | Shimano SLX SL-M7100-R | SRAM GX Eagle | Shimano Deore SL-M6100-R | SRAM GX Eagle | Shimano XT SL-M8100 | SRAM X0 Eagle | SRAM EA AXS 12 RH Rocker Controller | |
| REAR DERAILLEUR | - | - | Shimano Deore RD-M6100 | Shimano SLX RD-M7100 | SRAM GX Eagle | Shimano Deore RD-M6100 | SRAM GX Eagle | Shimano XT RD-M8100 | SRAM XO1 Eagle | SRAM X01 Eagle AXS |
| CRANKSET | - | - | Shimano Deore FC-MT6120-1, 32T, 170mm | Shimano SLX FC-M7100, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | SRAM GX Eagle, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | Shimano Deore FC-MT6120-1, 32T, 170mm | SRAM GX Eagle DUB, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | Shimano Deore XT FC-M8120-1, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | SRAM GX Eagle DUB, 34T (27.5), 32T (27.5 S), 32T (29), 170mm | SRAM Truvativ Decendent Carbon, 34T (27.5), 32T (27.5 S), 32T (29), 170mm |
| BOTTOM BRACKET | - | - | Shimano Sealed Bearing, BSA Threaded | Shimano Sealed Bearing, BSA | Sealed Bearing DUB, BSA | Shimano PF92 | SRAM DUB PF92 | Shimano PF92 | SRAM DUB PF92 | SRAM DUB PF92 |
| CHAIN TENSIONER | - | - | GW 1x Flip Guide | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide, DMB | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide | e*thirteen Vario Top Guide, DMB | e*thirteen Vario Top Guide, DMB |
| CASSETTE | - | - | Shimano Deore CS-M6100-12, 10-51T, 12 Speed | Shimano SLX CS-M7100-12, 10-51T, 12 Speed | SRAM Eagle XG 1275, 10-52T | Shimano Deore CS-M6100-12, 10-51T, 12 Speed | SRAM Eagle XG 1275, 10-52T | Shimano SLX CS-M7100-12, 10-51T, 12 Speed | SRAM Eagle XG 1275, 10-52T | SRAM Eagle XG 1295, 10-52T |
| CHAIN | - | - | Shimano Deore CN-M6100 | Shimano Deore CN-M6100 | SRAM Eagle | Shimano Deore CN-M6100 | SRAM Eagle | Shimano SLX CN-M7100 | SRAM Eagle | SRAM Eagle |
| FRONT BRAKE | - | - | Shimano Deore BR-MT420, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano SLX 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads |
| FRONT BRAKE ROTOR | - | - | Shimano RT-64, 203mm | Shimano RT-64, 200mm | SRAM CenterLine, 200mm | Shimano RT-64, 203mm | SRAM CenterLine, 200mm | Shimano RT-64, 203mm | SRAM CenterLine, 200mm | SRAM CenterLine, 200mm |
| REAR BRAKE | - | - | Shimano Deore BR-MT420, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano BR-MT520, 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | Shimano SLX 4 piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads | SRAM Code RSC, 4 Piston, Metallic Pads |
| REAR BRAKE ROTOR | - | - | Shimano RT-64, 180mm | Shimano RT-64, 180mm | SRAM CenterLine, 180mm | Shimano RT-64, 180mm | SRAM CenterLine, 180mm | Shimano RT-64, 180mm | SRAM CenterLine, 180mm | SRAM CenterLine, 180mm |
| BRAKE LEVERS | - | - | Shimano Deore BR-MT420 | Shimano BR-MT520 | SRAM Code RSC | Shimano BR-MT520 | SRAM Code RSC | Shimano SLX | SRAM Code RSC | SRAM Code RSC |
| HANDLEBAR | - | - | Butted 6061 Alloy, 800mm, 25mm Rise | Butted 6061 Alloy, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | Butted 6061 Alloy, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | Deity Ridgeline, 800mm, 25mm Rise | OneUp Carbon, 800mm, 20mm Rise |
| STEM | - | - | Alloy, 40mm Length, 35mm Clamp | e*thirteen Base, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Alloy, 40mm Length, 35mm Clamp | Norco CNC, 40mm Length. 35mm Clamp |
| SEATPOST | - | - | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | OneUp Adjustable Dropper, 34.9mm, 150mm (S), 180mm (M, L), 210 (XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | TranzX YS105, Adjustable Travel, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL) | OneUp Adjustable Dropper, 34.9mm, 150mm (S), 180mm (M, L), 210 (XL) | OneUp Adjustable Dropper, 34.9mm, 150mm (S), 180mm (M, L), 210 (XL) |
| HEADSET | - | - | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered | FSA #57 E Sealed Bearing, Tapered |
| SADDLE | - | - | WTB Volt 250 Sport | SDG Bel Air V3 | Fizik Alpaca Terra, Wingflex | SDG Bel Air V3 | SDG Bel Air V3 | SDG Bel Air V3 | Fizik Alpaca Terra, Wingflex | Fizik Alpaca Terra, Wingflex |
| GRIPS | - | - | SDG Thrice Lock-On, Thin (S, M), Thick (L, XL) | SDG Thrice Lock-On, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | SDG Thrice Lock-On, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) | DMR DeathGrip Soft, Thin (S, M), Thick (L, XL) |
| SEATPOST CLAMP | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm | Norco design alloy nutted clamp 38.5mm |
| FRONT HUB | - | Shimano HB-MT410 15x110mm Boost, Center Lock | Shimano SLX 15x110mm Boost, Center Lock | DT Swiss 350, 15x110mm Boost, 6 Bolt | Shimano HB-MT410, 15x110mm Boost, Center Lock | DT Swiss 370, 15x110mm Boost, 6 Bolt | Shimano SLX M7010, 15x110mm Boost, Center Lock | DT Swiss 350, 15x110mm Boost, 6 Bolt | DT Swiss 240, 15x110mm Boost, 6 Bolt | |
| REAR HUB | - | - | Shimano FH-MT510, 12x148mm Boost, Micro Spline, Center Lock | Shimano SLX, 12x148mm Boost, Micro Spline, Center Lock | DT Swiss 350, 12x148mm Boost, XD, 6 Bolt, 36T Engagement | Shimano FH-MT510, 12x148mm Boost, Micro Spline, Center Lock | DT Swiss 370, 12x148mm Boost, XD, 6 Bolt | Shimano SLX M7110, 12x148m Boost, Micro Spline, Center Lock | DT Swiss 350, 12x148mm Boost, XD, 6 Bolt | DT Swiss 240, 12x148mm Boost, XD, 6 Bolt |
| REAR HUB SKEWER | Norco 12mm TA alloy w/allen key | Norco 12mm TA alloy w/allen key | - | - | - | - | - | - | - | - |
| RIMS | - | - | WTB ST I30 TCS 2.0, 32H | Stan's Flow D, 32H | Stan's Flow S2, 32H | Stan's Flow D, 32H | Stan's Flow S2, 32H | Stan's Flow S2, 32H | DT Swiss M1700 Wheelset | |
| FRONT TIRE | - | - | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding | DT Swiss XMC 1501 Carbon Wheelset |
| REAR TIRE | - | - | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding | Maxxis Assegai 2.5" 3C Maxx Terra/EXO+/TR, Folding |
| SPOKES/NIPPLES | - | - | Stainless, Black | Stainless, Black | DT Swiss Competition DB Stainless Black | Stainless Black | DT Competition DB Stainless Black | DT Competition DB Stainless, Black | DT Swiss | Maxxis Minion DHR II 2.4" WT 3C, Maxx Terra/EXO+/TR, Folding |
| VALVES | - | - | WTB Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | Stan's 35mm Tubeless Presta | DT Swiss Tubeless Presta | DT Swiss |
| SEALANT | - | - | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | Stan's - 200ml | We Are One |
| PRICE | $1,999 | $3,499 | $3,499 | $4,399 | $5,699 | $5,199 | $6,199 | $6,299 | $7,099 | $9,999 |
